Prime Control Panel
Hybrid anti-intrusion and home automation control panel featuring extensive capabilities and integrated LAN connectivity
Prime: Hybrid anti-intrusion and home automation control panel for medium and large premises
Prime is a hybrid anti-intrusion and home automation control panel that combines wired and wireless technology, providing maximum security and flexibility. Ideal for medium and large residential, commercial and industrial premises, Prime offers a high level of customization through advanced programming, allowing the creation of events and actions tailored to every need. Grade 3 certified according to EN50131, it integrates all Inim peripherals for security and home automation functions, offering complete and customized management.
Advanced connectivity and full integration for a system that’s always connected
Prime supports advanced home automation with light, gate and window management and integrates with major protocols and standards such as API https, KNX, Modbus, Onvif and CCTV InVista. CloudReady, automatically connects to the Inim Cloud for remote control via app. Versatile connectivity includes PSTN, LAN, Wi-Fi, 2G/4G-GSM/LTE to ensure limitless management, even for installations of up to 500 terminals. It is part of the exclusive “Identified Installer” program to protect specialized installers, ensuring their exclusivity in the market.
Prime | 5.00 with CoreSync: smarter security design
Prime | Version 5.0 expands the capabilities of Prime control panels thanks to CoreSync, creating direct integration between the intrusion detection system, InVista NVR, and video analytics. The installer can configure up to 200 AI video ZONES per system—without using the control panel’s physical zones—and combine them with traditional sensors using programmable AND logic. The video surveillance system is no longer a separate component but becomes an active part of the security strategy: it verifies events, contributes to alarm conditions, and generates coordinated actions. Prime thus evolves into an even more flexible, scalable platform geared toward the design of integrated professional security systems.
Accessories and integration components
This product is available in the following versions
Prime060S
Anti-intrusion control panel with 10 to 60 terminals, 10 partitions
Prime060L
Anti-intrusion control panel with 10 to 60 terminals, 10 partitions
Prime120L
Anti-intrusion control panel with 10 to 120 terminals, 20 partitions
Prime240L
Anti-intrusion control panel from 10 to 240 terminals, 30 partitions
Prime500L
Anti-intrusion control panel from 10 to 500 terminals, 30 partitions
Technical Specifications
| PRIME060L | PRIME060S | PRIME120L | PRIME240L | PRIME500L | |
| Power supply voltage | 230 VAC ±15%, 50–60 Hz | 230 VAC ±15%, 50–60 Hz | 230 VAC ±15%, 50–60 Hz | 230 VAC ±15%, 50–60 Hz | 230 VAC ±15%, 50–60 Hz |
| Total maximum current deliverable | 6,2 A | 3,2 A | 6,2 A | 6,2 A | 6,2 A |
| Current for battery recharge | 1,2 A | 1,2 A | 1,2 A | 1,2 A | 1,2 A |
| Number of terminals | 60 | 60 | 120 | 240 | 500 |
| Number of partitions | 10 | 10 | 20 | 30 | 30 |
| Certifications | EN50131-3/EN50131-6 IMQ INCERT | EN50131-3/EN50131-6 IMQ INCERT | EN50131-3/EN50131-6 IMQ INCERT | EN50131-3/EN50131-6 IMQ INCERT | EN50131-3/EN50131-6 IMQ INCERT |
| Dimensions | 37 x 46 x 9 cm | 27 x 37 x 8.6 cm | 37 x 46 x 9 cm | 37 x 46 x 9 cm | 37 x 46 x 9 cm |
| Weight | 5 kg | 3.2 kg | 5 kg | 5 kg | 5 kg |
